Envo Flush

Single Flush Doors

Envo Flush

Single Flush Doors

A carpeted landing area with two flush single doors, one open and leading into a tiled bathroom.

The Envo Flush jib door system allows for a single or double door set to sit seamlessly into a wall with just a 2mm hairline gap between the door and frame whilst guaranteeing no cracked plaster. An invisible look is made possible by concealed hardware and a frameless finish, allowing a seamless transition of finishes across the wall and door leaf. Envo can supply a timber door leaf to your specification whether you're looking for a hidden or a contrasting finish. Envo Flush is the perfect long-lasting solution even in high-traffic areas thanks to our no plaster crack guarantee. FD30 fire-rating is available, for more information on this and other technical options refer to our technical specifications or speak to a member of the Envo team.

A carpeted landing area with two flush single doors, one open and leading into a tiled bathroom.
No visible frame
Guarantees no cracked plaster
Invisible strike plate
FD30 option available
Where to use a single flush door.

The invisible frame renders this system perfect for openings to hidden rooms and staircases, and because of its aesthetics it is often used throughout modern or minimalistic interiors.

The door leaf is optional but the majority of our clients purchase the door and kit through Envo. You can view our timber options here and our timber finishes here.

Invisible finish

There is no visible frame around the door, and a 2mm gap between the door and the frame: just a hair-line gap around the door.

The magnetic latch allows for no visible strike plate, and when the door is open, no visible latch.

No cracked plaster, guaranteed.

The rigid aluminium profile guarantees no cracks in the plaster, with the dovetail detail ensuring good adhesion to the plasterwork.

Door specification & fire-ratings

Suitable for all standard and non-standard door openings, and standard rebated doors.

The universal profile means you don’t have to compromise between pivoting for inward doors and hinged for outward opening doors as is typical with riser door systems on the market. Regardless of whether you want your door to open in or out, you can utilise the same mechanism.

Our single flush kit can be fire-rated to FD30 / EI30 BS EN 1634-1:2014.

Installation

This flush door leaf can be fitted before or after plastering, with full adjustability due to the adjustable upper profile.

Each profile is cut exactly to size for your project, and is suitable for brickwork, metal stud and timber frame walls.

What comes as part of the kit?

Here's what comes as part of the Envo Single Flush door kit. The frame profiles are supplied already primed for painting, so you can match the finishes on site.

Aluminium frame, cut to size
Hinges
Magnetic lock
Impact seals
Looking at the side profile of an open door with a magnetic latch, black lever handles and in a brick feature wall and steel rail in the background.
Gallery.

Examples of the Envo Single Flush door system in action.

flush invisible jib door with a plaster finish in a hotel spa
flush invisible jib door with a plaster finish in a hotel spa
A carpeted corridor with a flush door at the end leading into a bedroom. Foreground with steel rail, brick feature wall and white walls and doors.
Carpeted corridor with brick feature wall and steel rail leading to a closed white flush door with a black cat sitting in front.
Looking down at a carpeted floor and the corner of a white flush door open showing the hinge detail.
A black, grey and white tiled room with a plant in a black pot with two white invisible flush doors with silver lever handles.
A white door slighly ajar leading into a tiled room, door with a black lever and privacy lock and white keep in the frame.
A carpeted landing area looking straight on at two closed flush doors with a pale blue chesterfield sofa in the foreground.
A carpeted landing area with two flush single doors, one open and leading into a tiled bathroom.
A carpeted landing area with a side view of two open doors with invisible frame hinges.
Looking at the side profile of an open door with a magnetic latch, black lever handles and in a brick feature wall and steel rail in the background.
Looking at the floor detail of an open flush door .
A large neutral coloured landing area with a view to the garden through steel glazed window panes and two large closed white flush doors with an abstract canvas painting.
Door finishes
Envo Flush door leaves come in a range of veneers, painted, or in a primed finish ready for painting. Examples of our timber veneers are shown below, however, other options can be sourced if required.
Primed
Birch veneer for internal doors
Birch
Birds Eye Maple veneer for internal doors
Birds Eye Maple
Quarter Cut Maple
Crown Cut Maple

Related products.

Discover the rest of our internal jib door systems for a seamless, concealed look.

Double Flush Doors
Pivoting Flush Doors
Timber Doors
How we support.

You have our support from initial sketches through to the final install. We'll visit site to advise on product selection and we'll be back if you need installation support.

We are able to provide detailed door schedules as part of our service and support package.
